Professional Series

7.75 Gross Torque*

The Professional Series engines were designed to deliver a best-in-class experience combining power, performance, features, and size. These engines offer consumers and professionals commercial-grade features including easier starting, smoother and quieter operation, increased durability, and longer life. ReadyStart® is standard on all Professional Series engines.

Briggs 7.75 TP

Professional Series
7/8″ x 2-7/16″ shaft, tapped 3/8″-24 with 3/16″ keyway.

Non-compliance engine, heavy flywheel.

Universal replacement engine for pressure washers, log splitters, and other types

of engines that do not need a flywheel brake, or that have a mower blade attached.

Ready Start, no choke- no priming.

Remote throttle design.

2 year consumer/ 1 year commercial warranty.

3800 rpm top speed setting.

Model 111P02-0003

CARB approved for sale in California.

36 lbs

Feature	Benefit
Large 175cc Displacement – 7.75 ft.-lbs. Gross Torque*	Delivers maximum power and torque for heavy-duty applications
ReadyStart® Starting System	No priming or choking required, just pull the cord for hassle-free starting
Our Starting Promise	Starts in 2 pulls or Briggs will fix it for free
Overhead Valve Design	Runs cooler and cleaner delivering more power, longer engine life, and improved fuel economy
Large Diameter Rewind Starter	Requires less pull force during starting
One-Start Carburetor	Float-feed carburetor for consistent one-pull starts
Tube-Outlet Muffler	Reduces noise levels and improves tonal quality
Commercial-Grade Air Management System	Dual-seal design for less debris intake and longer element and engine life

Engine Specifications

Engine Fuel	Gasoline
Configuration	Vertical
Cylinders	One
SKU	111P02-0003-F1
Top No Load Speed	SET ENG NO-LOAD SPEED TO 3100 +/-100 RPM
Oil Capacity	20 fl. oz.
Air Cleaner	AIR CLEANER, DUAL ELEMENT OVAL
Air Cleaner Cover	AIR CLNR COVER, 290 SATIN BLACK
Bearings	BEARINGS, PLAIN PTO
Blower Housing	REWIND COVER, LS, 290 SATIN BLACK
Bore Type	Koolbore
Piston Bore Size	2.6
Piston Stroke	2
Casing Clamps	CASING CLAMP & SCREW, WITHOUT
Controls Groups	CONTROL GROUP 73, MODEL 11/12
Cylinder Head	CYLINDER, ALUMINUM
Deflectors	DEFLECTORS, WITHOUT
Dipsticks	DIPSTICK, OPPOSITE CARB SIDE
Oil Drain	OIL FILL, OPPOSITE CARB SIDE
Misc	FUEL HOSE, LOW PERM VERSION
Flywheel	FLYWHEEL, HVY, CAST IRON, REW ONLY
Governor	MECHANICAL GOVERNOR
Exhaust	MUFFLER, PERFORMANCE W/TUBE OUTLET INST (SMALL)
Spark Plug	SPARK PLUG, RESISTOR
Starting System	STARTER, REWIND POSITION – 5:30 O’CLOCK

Click to enlarge

Briggs and Stratton Vertical Engine 7.75TP 7/8″ x 2-7/16″ HF #111P02-0003

Name: Briggs and Stratton Vertical Engine 7.75TP 7/8″ x 2-7/16″ HF #111P02-0003
SKU: 53707
Availability: InStock

$270.00

50 in stock

Estimated delivery dates: Apr 26, 2026 - May 1, 2026

Add to compare

Add to wishlist

Categories: Accessories, All Products Tags: #.free-shipping, BRIGGS 18 OIL, ENGINES | Briggs and Stratton Engines | Briggs Vertical Shaft Engines

Description

Feature	Benefit
Large 175cc Displacement – 7.75 ft.-lbs. Gross Torque*	Delivers maximum power and torque for heavy-duty applications
ReadyStart® Starting System	No priming or choking required, just pull the cord for hassle-free starting
Our Starting Promise	Starts in 2 pulls or Briggs will fix it for free
Overhead Valve Design	Runs cooler and cleaner delivering more power, longer engine life, and improved fuel economy
Large Diameter Rewind Starter	Requires less pull force during starting
One-Start Carburetor	Float-feed carburetor for consistent one-pull starts
Tube-Outlet Muffler	Reduces noise levels and improves tonal quality
Commercial-Grade Air Management System	Dual-seal design for less debris intake and longer element and engine life

Engine Fuel	Gasoline
Configuration	Vertical
Cylinders	One
SKU	111P02-0003-F1
Top No Load Speed	SET ENG NO-LOAD SPEED TO 3100 +/-100 RPM
Oil Capacity	20 fl. oz.
Air Cleaner	AIR CLEANER, DUAL ELEMENT OVAL
Air Cleaner Cover	AIR CLNR COVER, 290 SATIN BLACK
Bearings	BEARINGS, PLAIN PTO
Blower Housing	REWIND COVER, LS, 290 SATIN BLACK
Bore Type	Koolbore
Piston Bore Size	2.6
Piston Stroke	2
Casing Clamps	CASING CLAMP & SCREW, WITHOUT
Controls Groups	CONTROL GROUP 73, MODEL 11/12
Cylinder Head	CYLINDER, ALUMINUM
Deflectors	DEFLECTORS, WITHOUT
Dipsticks	DIPSTICK, OPPOSITE CARB SIDE
Oil Drain	OIL FILL, OPPOSITE CARB SIDE
Misc	FUEL HOSE, LOW PERM VERSION
Flywheel	FLYWHEEL, HVY, CAST IRON, REW ONLY
Governor	MECHANICAL GOVERNOR
Exhaust	MUFFLER, PERFORMANCE W/TUBE OUTLET INST (SMALL)
Spark Plug	SPARK PLUG, RESISTOR
Starting System	STARTER, REWIND POSITION – 5:30 O’CLOCK
