Name: CountyLine 3,625 PSI G Series Directional Control Valve, 10 GPM, 2 Spool, SAE 10 Inlet/Outlet
SKU: 42395
Availability: InStock

CountyLine 3,625 PSI G Series Directional Control Valve, 10 GPM, 2 Spool, SAE 10 Inlet/Outlet

$160.00

33 in stock

Estimated delivery dates: Apr 21, 2026 - Apr 26, 2026

Use the CountyLine 3,625 PSI G Series Directional Control Valve with a variety of hydraulic tools. Featuring up to 3,625 PSI, this directional control valve comes with a 3-position spring center and a 4-way, 3-position tandem center. The control valve operates in a maximum 176 degrees F temperature, and includes an anti-drop load check on each spool to ensure safety. The control valve is made of durable cast-iron construction, ensuring longevity and added strength.

Cast-iron construction provides durability
Universal compatibility enables easy use
10 GPM, SAE 10 inlet, SAE 10 outlet and SAE 10 work ports
Delivers adjustable relief up to 3,625 PSI
Control valve has a 10 GPM flow rate
4-way, 3-position tandem center
3-position spring center
176 degree F maximum operating temperature
Anti-drop load check on each spool allows safe use
Control valve is equipped with 2 spools
Power beyond or closed center are available
Complete handle assembly included
Backed by a 1-year warranty

Brand	CountyLine
Country of Origin	Imported
Brand Compatibility	Universal
Compatibility	Most applications
Inlet Size	SAE 10
Inlet Type	Female
Maximum Flow Rate	10 GPM
Maximum PSI	3,625 PSI
Model Compatibility	Most applications
Number Of Directional Control Positions	3
OEM Replacement	Control valve
Outlet Size	SAE 10
Outlet Type	N/A
Primary Material	Cast Iron
Product Height	0 N/A
Product Length	0 N/A
Product Weight	9.4 lb.
Product Width	0 N/A
Warranty	1 Year
Work Port Size	SAE 8
Manufacturer Part Number	310907
