Electric Pallet Jack | Lithium Iron |3300 lbs Capacity | EKKO EP15SLI

Description EKKO Lithium Walkie Pallet Jack 4000 lb Capacity EP18JLIC Product Description The EKKO EP18JLIC Lithium Walkie Pallet Jacks are designed with the versatility of a pallet jack with full power lifting and driving capabilities. It is ideal for loading and unloading trucks, loading docks, stock rooms, manufacturing floors and warehousing. Made from high quality steel and components with durable quality drives to withstand any terrain, usage, impact and directional changes for the use of any application with confidence and assurance. Lithium 24V Powered Load Capacity 4000 lb Fork Size 2.2×45.2 Raised Height 7.48″ Lowered Height 2.95″ Pinwheel Capability Polyurethane Wheels Ergonomic Handle and Controls Steel Construction Robotic Welding Charger Included Battery Included 3 Years Limited Warranty About EKKO Lifts Specification Model EP18JLIC Drive type Electric Manner of operation Walkie Load Capacity 4000 Q (LBS) Load Centre 23.6 c (Inch) Axle centre to fork face 37 x (Inch) Wheel Base 50.3 y (Inch) Tire material Polyurethane Driving wheel size Φ8.27×2.95 Φ×w(Inch) Bearing wheel size Φ2.91×3.66 Φ×w(Inch) Qty of wheel，Front/Rear（x=driving wheel） 1x/2 Tread 21.06 b11 (Inch) Lifting Height 7.48 h3 (Inch) The height of handle in the operation position 48.2 h14 (Inch) Lowered fork height 2.95 h13 (Inch) Overall Length 64 l1 (Inch) Body Length 16.53 l2 (Inch) Overall Width 27 b1/ b2 (Inch) Fork Size 2.24/6.3/45.28 s/e/l (Inch) Fork Width 27 b5 (Inch) Min.Ground clearance 1.06 m2 (Inch) Aisle width for pallets 39.37*47.24 crossways 88.9 Ast (Inch) Aisle width for pallets 31.5*47.24 lengthways 83.9 Ast (Inch) Turing Radius 57.5 Wa (Inch) Driving Speed，load/unload 2.6/2.8 (km/h) Maximum gradeability load/unload 0.24/0.39 (in/s) Brake Type Electromagnetic brake Drive Motor 0.75 (kW) Lift Motor 0.8 (kW) Lithium LiFePO4 Battery voltage rate capacity 24/40 (V/Ah) Battery Weight（±5%） 21.1 LBS Type of drive control DC Noise level ≤70 (dB(A)) Service Weight（with battery） 346 LBS Product Documents Product User Manual Product Service Manual Warranty
